Genuine Chrysler 200 Shock Absorber
Suspension Shock Absorber- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
27 Shock Absorbers found
| Page 1 of 2 |Next >
1-20 of 27 Results
Chrysler 200 Shock Absorber
The Shock Absorber can be described as a key component in Chrysler 200 where the manufacturer aims at reducing excessive bouncing in auto vehicles while at the same time enhancing the quality of ride. Through hydraulic means, the Shock Absorber translates kinetic energy to heat that helps minimize the shock impulses of a car thereby improving handling and comfort at any type of terrain. It important to note that throughout the years various models of Chrysler 200 incorporated distinct types of Shock Absorbers, twin-tube and mono-tube being some of those types. Twin-tube shocks are typical, and their construction is very simple, which enables them to be gas charged for the increased service life. Unlike, mono-tube shock absorbers provide better heat transfer and performance and can be fitted in multiple ways. Optional features such as PSD and ASD allow for customization to specific drive conditions, technologies like the electrorheological damper also presents an adaptive Dampening capability.
Looking for affordable and high-quality auto parts? Then you have already arrived at the proper online shop. We offer all Chrysler 200 Shock Absorber at great affordable prices. Moreover, all genuine Chrysler 200 Shock Absorber come with a manufacturer's warranty. In the long run, you would realize you have saved a lot of trouble and money with OEM parts from here.
Chrysler 200 Shock Absorber Parts Questions & Experts Answers
- Q: How to remove and install the rear coil springs and shock absorber on Chrysler 200?A:For 2014 and earlier models, start by removing the trim panels from the sides of the trunk to access the shock absorber upper mounting fasteners. Then, loosen the rear wheel lug nuts, raise the vehicle, and support it on jackstands. Remove the rear wheels. In the trunk, remove the two nuts that hold the shock absorber to the vehicle body. If equipped, remove the trim panels covering the lower Control Arm. Finally, remove the shock absorber lower mounting nut and bolt to remove the shock unit. For 2015 and later models, raise the rear of the vehicle and support it on jackstands. Remove the wheels and the rear fenderwell splash shield. Use a floor jack to support the knuckle and raise it slightly. Remove the shock absorber lower mounting bolt. If necessary, loosen the fuel filler tube bolt and move the filler tube aside for better access to the shock upper mounting bolts. Remove the shock absorber upper mounting bolts and the shock absorber assembly from the vehicle. If needed, transfer the shock upper mount to the new shock and tighten the center nut. For all models, grease the lower mount with white lithium grease for easier installation and to prolong the life of the lower shock bushing. If you plan on removing the springs and overhauling the shock unit, follow the procedures. On 2014 and earlier models, ensure that the side of the upper mount that protrudes more is facing towards the outside of the vehicle. On 2015 and later models, tighten the shock absorber upper bolts. Raise the rear suspension with a floor jack positioned under the knuckle to simulate normal ride height, then tighten the lower mounting bolt. Install the wheel and lug nuts, lower the vehicle, and tighten the lug nuts. On 2014 and earlier models, tighten the shock absorber upper mounting nuts. Finally, reinstall the trim panels in the trunk.
