Chrysler 5017992AA Battery

Battery can only be tested to the desired capacity when it is full or nearly full. Disconnect the negative battery cable and perform the following tests: First it is recommended to examine the state of the indicator eye on battery and if it is darker then charge the battery. In batteries that have ports that allow electrolyte observation, ensure it goes up to and slightly above the plates and if it is low, add distilled water though not to the top. Hydrometer should be used to test the specific gravity, and the result should be in the range of 1.270 at 20 degree centigrade open circuit voltage should be tested by digital voltmeter prior to the commintent of the subsequent steps must be over 12.5 volts. For the battery load test take a load tester to test the battery in terms of high amperage load that should be maintained for 15 seconds at which time the battery voltage should not be low than 9.6 volts. Temperature condition may need to be made on the minimum voltage for operations. An electrical system drain is measured by a battery drain test which is supposed to register a normal drain of about 100 milliamps when the reading is constant. When battery is being replaced, the negative terminal must be removed first, before the battery is replaced and the negative terminal connected after the positive one. Disconnect the air filter housing cover, undo and disconnected both battery cables and unbolt the battery hold-down clamp. Check stainless metal battery tray for rusting and clean it if it is rusty. Replace with a new battery that equates the originals, then reassemble in the reverse manner, but be careful not to over tighten the hold-down clamp.

First of all, it deals with battery maintenance and charging. It insists on servicing the battery regularly to ensure it starts well and does not pose a risk. The implication is that before any service, one should turn off the engine as well as disconnect the negative terminal. The section indicates that a corrosion check, cleaning of clamps and terminals, inspection, and finding out where it is kept in the car is needed. If it needs to be recharged, then it should be done at a slow rate; it should not be quick-charged is another warning in this part. Finally, a guide on how to connect the charger, test its output voltage, and take readings of specific gravity while charging are also included in this section. This information will help you keep your battery in top condition so that you enjoy optimum performance from it and a longer life span.
