Mopar 53004245 Oxygen Sensor

You can Select Your Vehicle to check if 53004245 fits your vehicle.

The engine coolant temperature sensor, a thermistor that varies resistance with temperature, is essential for the vehicle's operation. Testing involves measuring its resistance when cold and warm; a significant difference could indicate sensor failure. Replacing it necessitates preparing the new sensor with Teflon sealing, unplugging the electrical connector, and swiftly replacing the sensor to minimize coolant leakage. The manifold absolute pressure (MAP) sensor monitors intake manifold pressure changes, aiding the ECM in fuel delivery and ignition timing control. Testing involves connecting jumper wires, and a voltmeter should read about 4.5 to 5 volts with the ignition on and fluctuate when the engine warms up; failure may trigger Code 3Replacement requires detaching the vacuum hose, unplugging the electrical connector, and removing mounting screws. The oxygen sensor, positioned in the exhaust system, monitors exhaust gas oxygen content to inform the ECM's fuel mixture control. Testing with a voltmeter at normal operating temperature should result in voltage fluctuations; a lack of variation might indicate sensor or fuel system issues, leading to Code 13 or 4 The throttle position sensor (TPS) on the carburetor float bowl helps the ECM determine fuel delivery based on throttle valve angle. Check its resistance with an ohmmeter, and if it's inconsistent instead of progressive as you move the throttle, replace it. Replacement involves unplugging the electrical connector and removing the TPS assembly. Adjustment, if needed, requires drilling a hole in the adjustment screw's plug, connecting terminals, and adjusting the screw to achieve a specific voltage reading. Finally, the plug is replaced or sealed with RTV.

Information sensors provide the computer with data on the engine's operating conditions, allowing for adjustments to be made to improve fuel economy and reduce emissions. The oxygen sensor, located in the exhaust manifold or down pipe, measures the oxygen content in the exhaust and sends a voltage signal to the computer to adjust the fuel/air mixture. The knock sensor detects engine detonation and sends impulses to the computer to retard ignition timing. The coolant temperature sensor monitors coolant temperature and provides input to the computer for fuel/air mixture and ignition timing adjustments. The manifold absolute pressure sensor reads pressure changes in the intake manifold to vary the air/fuel mixture. The manifold air temperature sensor measures air temperature in the intake manifold to adjust the fuel/air mixture. The throttle position sensor senses throttle movement and position to transmit an electrical signal to the computer. The crankshaft position sensor detects engine speed and crankshaft angle for ignition timing and fuel injector control. The vehicle speed sensor sends a voltage signal to the computer to determine vehicle speed.

The procedure for replacing the oxygen sensor is detailed in another part of the manual.
