Genuine Chrysler Fuel Tank
Gas Tank- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
88 Fuel Tanks found
Product Specifications- Other Name: Tank-Fuel
- Replaces: 68166587AA, 68166587AC, 68166587AB
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68258723AD
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68051891AB
Product Specifications- Other Name: Tank-Fuel
- Replaces: 68421772AA
Product Specifications- Other Name: Tank-Fuel
- Position: Rear
- Replaced by: 68051891AB
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68258723AD
Product Specifications- Other Name: Tank-Fuel
- Replaces: 4721841AF
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68166634AF
Product Specifications- Other Name: Tank-Fuel
- Replaces: 5085019AB
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68320183AD
Product Specifications- Other Name: Fuel Tank
- Replaces: 68494592AA
Product Specifications- Other Name: Fuel Tank
- Replaced by: 68320183AD
- Replaces: 68320183AB, 68320183AA
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68258722AD
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68258723AD
Product Specifications- Replaced by: 68524825AB
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68494592AB
Product Specifications- Other Name: Tank-Fuel; Fuel Tank
- Replaces: 68319398AA, 68319398AB
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 5085019AC
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68217191AF
Product Specifications- Other Name: Tank-Fuel
- Replaced by: 68217191AF
| Page 1 of 5 |Next >
1-20 of 88 Results
Chrysler Fuel Tank
Our website has a huge selection of Chrysler Fuel Tanks at the optimal prices in the industry. If you need any genuine Chrysler Fuel Tanks, we ship them to your door step as we offer a fast delivery service. In addition, all OEM parts are backed by the manufacturer's warranty.
Chrysler Fuel Tank Parts Questions & Experts Answers
- Q: How to remove the fuel tank on Chrysler Cirrus?A:To perform this process first, it requires removing the fuel tank filler cap, so that the pressure could be released. Do fuel pressure relief procedure and remove the negative terminal from the ground stud on the left shock tower. Inside the trunk, look to the left shock tower and fold back the mat there: there is a 4-pin connector for the fuel pump wiring harness; pull this connector off. Go down along the wire to the grommet located at the lower part of the rear seat, push the grommet in the hole in the floor pan and install the wiring and the connector through it. Loosen the fuel tank drain plug while the vehicle is on the ground in a level surface, fill an approved gasoline container and place it under the fuel tank drain plug, taking into consideration the use of the funnel in order to avoid any spillage of fuel when it is being drained. Open the drain plug and let the fuel to flow from the tank and close and tighten the drain plug. Open the clamp and remove the filler neck hose from the fuel tank and leave the quick-connect fuel line of fittings connected to the fuel pump module. At the back part of the fuel tank, remove the vapor hose connection of the rollover valve. Secure the position of the fuel tank by placing a floor jack underneath it; put a piece of wood twixt the jack head and the fuel tank. Take out the fuel tank strap bolts, and straps also. For 1998 models, lower the tank slightly and disconnect the EVAP canister purge line, remove the hoses from the EVAP canister, and remove the electrical connector from the Leak Detection Pump, be sure to label the hoses and fittings for reinstallation. Lower the fuel tank a little in order to remove the rear suspension crossmember then pull the fuel tank out of the car. To remove, undo the procedures mentioned above and fasten a piece of string or wire to the fuel pump module wiring harness then run the wire through the hole at the trunk floorpan of the car. After placing the tank safely secure to the car then pull the string to expose the wiring harness and tighten the fuel tank strap bolts to the torque required.
- Q: How to remove and reinstall a fuel tank on Chrysler PT Cruiser?A:In order to take out the fuel tank, the first step is to unscrew the fuel filler cap a little to release the pressure inside then releasing the system's fuel pressure. Then, bevor the metal with a piece of metal functioning as a ground then, unscrew the nut on the negative terminal of the battery and take out the cable. Lift the car to a safe working height and support it using jackstands on the rear part of the car. Place a drain pan with a capacity of not less than sixteen gallons under the drain cap, remove the fuel tank drain cap, and let the tank drain as long as necessary before replacing the cap. Pull off the vapor hose, unscrew the fuel filler neck hose clam and separate the fuel filler neck hose from the fuel inlet pipe. Put a transmission jack or floor jack in a position to the fuel tank but put a plywood on the head of the jack to avoid scratching it. Pull both of the fuel pump and leak detection electrical connectors, the EVAP line and the quick-connect fitting on the fuel supply hose. Loosen and take out the bolts that holds the fuel tank straps and then slowly dropped the fuel tank of the vehicle. For installation, the process done in the reverse way with the reminder of making sure that the fuel tank strap bolts are tightened and the engine started to look for any leaks at the fuel line connectors that were removed.
