Genuine Dodge Speed Sensor
Speed Control Sensor- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
97 Speed Sensors found
Dodge Sensor-Transmission Output Speed
Part Number: 4800879$53.41 MSRP: $75.00You Save: $21.59 (29%)Product Specifications- Other Name: Sensor Transmission Output Speed
Dodge Sensor-Transmission Output Speed
Part Number: 68019930AA$158.63 MSRP: $239.00You Save: $80.37 (34%)Product Specifications- Other Name: Sensor Transmission Output Speed
Product Specifications- Other Name: Front Speed Sensor
- Replaces: 68261168AA, 68261168AB, 68261168AC
Product Specifications- Other Name: Sensor Anti-Lock Brakes
- Replaced by: 68199988AE
Product Specifications- Other Name: Sensor Anti-Lock Brakes; ABS Sensor, Front Speed Sensor
- Replaced by: 68199988AE
Product Specifications- Other Name: Sensor Wheel Speed
Dodge Sensor-Transmission Input Speed
Part Number: 4799061AB$41.94 MSRP: $60.00You Save: $18.06 (31%)Product Specifications- Other Name: Sensor Transmission Input Speed
Product Specifications- Other Name: Sensor Wheel Speed
- Replaced by: 52125003AD
Dodge Sensor-Transmission Output Speed
Part Number: 52854001AA$67.50 MSRP: $101.00You Save: $33.50 (34%)Product Specifications- Other Name: Sensor Transmission Output Speed; Output Sensor, Vehicle Speed Sensor
Product Specifications- Other Name: ABS Sensor, Front Speed Sensor, Rear Speed Sensor
- Replaces: 68199987AC, 68199987AA, 68199987AB
Product Specifications- Other Name: Sensor Anti-Lock Brakes; ABS Sensor, Front Speed Sensor
- Replaced by: 68569551AA
Product Specifications- Other Name: Sensor Anti-Lock Brakes
- Replaced by: 68199987AD
Product Specifications- Other Name: Sensor-Anti-Lock Brakes; ABS Sensor, Front Speed Sensor
- Position: Passenger Side
- Replaces: 5085822AC, 5085822AB
Product Specifications- Other Name: ABS Sensor, Rear Speed Sensor
- Position: Driver Side
- Replaces: 4779643AB, 4779643AD
- Product Specifications
- Other Name: Front Speed Sensor; ABS Sensor
- Position: Driver Side
- Replaces: 5085823AC, 5085823AB
Product Specifications- Other Name: ABS Sensor, Front Speed Sensor
Product Specifications- Other Name: Sensor Wheel Speed; ABS Sensor, Rear Speed Sensor
Product Specifications- Other Name: ABS Sensor, Front Speed Sensor
- Replaces: 68250893AA
Product Specifications- Other Name: ABS Sensor, Rear Speed Sensor
- Replaces: 5154230AD, 5154230AB, 5154230AC, 5154230AF, 5154230AA, 5154230AE
Product Specifications- Other Name: Sensor Anti-Lock Brakes; ABS Sensor, Rear Speed Sensor
- Replaces: 5290248AA
| Page 1 of 5 |Next >
1-20 of 97 Results
Dodge Speed Sensor
Our website provides genuine Dodge Speed Sensors at competitive prices in the market. All of our OEM Dodge Speed Sensors come with the assurance of the manufacturer's warranty, a stress-free return policy, and speedy delivery service. So, you can shop with confidence.
Dodge Speed Sensor Parts Questions & Experts Answers
- Q: How to replace speed sensors in different types of automatic transmissions on Dodge Challenger?A:This procedure applies only to the 42RLE (hydraulic, with adaptive electronics) automatic transmission, where the input speed and output speed sensors are located on the left side of the transmission housing, with the input speed sensor being the forward unit and the output speed sensor the rear one. In the NAG1 (all-electronic) transmission, the two speed sensors are located inside the control unit on top of the valve body, and replacing either sensor requires a professional automatic transmission specialist. For the BHP45/BHP45RE transmissions, these sensors are integral components of the Transmission Control Module (TCM) and cannot be serviced separately. To replace a sensor, first raise the vehicle and secure it on jackstands, then locate the transmission speed sensor to be replaced and place a drip pan underneath, as some ATF will leak out upon removal. Disconnect the electrical connector from the speed sensor, then remove the mounting bolt. Installation is the reverse of removal; if reinstalling the old sensor, ensure the O-ring is in good condition and apply a non-hardening thread locking compound to the threads of the mounting bolt.
- Q: How to disconnect and replace the Vehicle Speed Sensor on Dodge Neon?A:First of all, remove the black cable of the battery. The VSS is situated on the upper part of the transaxle extension housing adjacent to one of the inner CV joints, and can be reached either from the top, involving the removal of the air filter housing, battery, and battery tray bracket, or from below, with the help of securely jack-up the car on jackstands. For all models with a manual transaxle, unplug the VSS electrical connector, then remove the VSS retaining bolt and take the VSS out, then remove the pinion driven gear and durch the old O-ring. Replace this with a new O-ring coated and cleaned with fresh oil; replace the drive gear and VSS and fasten it with the retaining bolt tightened to the recommended torque. For the year 2000 and 2001 models fitted with an automatic transaxle, the VSS electrical connector should be disconnected, the hold-down bolt to be undone and the VSS assembly to be taken out and while doing this the pinion driven gear should be swapped if required. Remove the old O-ring and replace it with a new one; clean the oil on the new O-ring and then install the pinion driven gear and make sure it is well seated in its proper place. For the cars made in 2002 and further, you have to disconnect the input shaft VSS electrical connector, to unscrew and to take out the input shaft VSS, then you have to discard an old O-ring and to install a new one, before a regular tightening of the given sculpture to the prescribed happy-turns of torque. The process is virtually repeated on the output shaft VSS where you first detach the electrical connector, loosen the VSS, remove the messed up O-ring, and replace it with a new one before Tightening the VSS output shaft.
