Genuine Jeep Wrangler Oil Pan
Oil Drain Pan- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
27 Oil Pans found
| Page 1 of 2 |Next >
1-20 of 27 Results
Jeep Wrangler Oil Pan
The Oil Pan in Jeep Wrangler vehicles is used in holding the engine oil in place to facilitate adequate lubrication of the motor parts. Located at the immediate bottom of the engine, the Oil Pan acts to avoid oil from dripping off the lubrication system. It has a place for the drain plug to allow for easy draining of the oil but over-tightening of this plug causes wear of the gasket and the Oil Pan. Therefore, a variety of styles of Oil Pan have been used in the different Jeep Wrangler models in the different years. The standard design has reasonable efficiency, yet problems like oil sloshing during intense cornering for example can be noticed, which can interfere with lubrication. To eliminate these problems, other systems such as 'dry sump' are used in high performance applications using scavenge pumps for constant supply of oil.
Looking for affordable and high-quality auto parts? Then you have already arrived at the proper online shop. We offer all Jeep Wrangler Oil Pan at great affordable prices. Moreover, all genuine Jeep Wrangler Oil Pan come with a manufacturer's warranty. In the long run, you would realize you have saved a lot of trouble and money with OEM parts from here.
Jeep Wrangler Oil Pan Parts Questions & Experts Answers
- Q: How to replace the oil pan and oil pump in 4.0L and 4.2L V6 engine on Jeep Wrangler?A:Disconnect the negative cable from the battery, raise the vehicle and support it securely on jackstands, then remove the belly pan from under the front of the engine. Drain the oil and replace the oil filter, followed by removing the starter motor and the bellhousing inspection cover from the front of the transmission. Detach the steering damper from the center steering link, support the front axle with a jack, and remove the lower shock absorber bolts. Lower the jack to allow the axle to hang free, then mark the locations of the oil pan mounting studs with paint for proper reassembly. Remove the oil pan mounting bolts/studs and carefully separate the pan from the engine block, gently tapping the side of the pan with a soft-face mallet if it sticks. If necessary, set the oil pan on the axle and remove the oil pump and pick-up tube, detaching the oil pump after removing the two attaching bolts. Slide the oil pan out to the rear, thoroughly clean the mating surfaces, and check the oil pan flange for distortion and warpage, straightening it if needed. Position new gaskets on the pan with Jeep Spray-a-Gasket or equivalent, applying RTV sealant at the corners where the gaskets join and coating the inside curved surface of the replacement rear gasket section with soap. Slide the oil pan up under the engine, reinstall the oil pump and pick-up tube, tightening the oil pump mounting bolts to the specified torque, then install the oil pan and tighten the bolts to the specified torque, working from the center out in several steps. Reinstall the remaining parts in reverse order of removal, check that the drain plug is tight, and add the specified amount of oil before running the engine to check for oil leaks.
