Diagram (1 of 1): HEATER AND AIR CONDITIONING PLUMBING, AIR CONDITIONING AND HEATER B,T MODELS
1986 Dodge Ram Van Plumbing - A/C & Heater Diagram
Enlarge Diagram
Sort by:
Ref No.
Ref No.
Part No. & Part Description
Price
Part No. &
Part Description
  • 3
    3847829
    DRIER, Filter
  • 4
    3849240
    VALVE, Expansion
    used w/o Low Pressure Cut-Off Switch
  • 4
    4176999
    VALVE, Expansion
    used with Low Pressure Cut-Off Switch
  • 5
    5210377
    SWITCH, Low Pressure Cut Off Aux.
  • 6
    6025004
    NUT
  • 7
    4261312
    HOSE, Suction and Liq.
    w/Auxiliary, w/318,360 Engine
    • Fitting Vehicle Options:
      B
  • 7
    4361080
    HOSE, Suction and Liq.
    w/225 Engine
  • 7
    4361081
    HOSE, Suction and Liq.
    w/o Auxiliary, w/318,360 Engine
  • 8
    4261027
    HOSE, Discharge
    w/225 Engine
    • Fitting Vehicle Options:
      B
  • 8
    4261028
    HOSE, Discharge
    w/318,360 Engine
    MSRP: --
    $0.00
  • 9
    4163990
    MUFFLER, w/225 Engine, Discharge
  • 11
    4114165
    TUBE, w/PLATE
    w/225 Engine, A/C. Suction 1986, up to 5-5-86
    • Fitting Vehicle Options:
      B
  • 11
    4261318
    TUBE, w/PLATE
    w/318,360 Engine, Suction Liquid
  • 11
    4353002
    TUBE, w/PLATE
    after 5-5-86
  • 11
    4353002
    TUBE, w/PLATE
    1987
    • Fitting Vehicle Options:
      B
  • 12
    3848585
    CAP
  • 13
    6500827
    SCREW, w/WASHER
    • Require Quantity:
      2
  • 15
    2219384
    O-RING, Discharge Line
  • 16
    2219385
    O-RING, Suction Line
  • 17
    3849406
    SWITCH, A/C. Damped Cycling Pressure with O Ring
  • 19
    3847147
    PILOT, Discharge and Suction Liq. Line Mtg.
  • 4114754
    BRACKET, Drier
  • 3848021
    CAP, A/C Check Valve Fitting
  • 3847081
    GASKET, Disch. or Suction Ftg. Mtg. to Compressor
  • 3847083
    GASKET, Line to Drier
  • 3846834
    GASKET, Suct. Liq. Mtg. to H-Valve
  • 2837498
    SLEEVE, A/C Heater Eng. to Val. Hose
  • 3846134
    STRAP, Drier
  • 4339463
    SWITCH, A/C. Suction and Line Temp. Sensing
  • 3849406
    VALVE, A/C. Damped Pressure Switch Ftg.
    SWITCH, A/C. Damped Cycling Press
  • 3849468
    VALVE, A/C. Damped Pressure Switch Ftg.
    VALVE, A/C. Damped Pressure Switch Ftg.
  • 3847576
    VALVE, Discharge and Liq. Line Check 1986
