Genuine Dodge Intake Manifold
Engine Intake Manifold- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
184 Intake Manifolds found
Product Specifications- Other Name: Manifold-Intake; Intake Plenum
- Replaces: 5184199AE
Product Specifications- Other Name: Intake Manifold
- Replaces: 68190715AC
Product Specifications- Other Name: Manifold-Intake Manifold ; Plenum Intake Manifold; Intake Manifold, Intake Plenum, Plenum
- Replaces: 68621090AA
Product Specifications- Other Name: Manifold-Intake
- Replaces: 4593915AA
Dodge Intake Manifold W/Imc Solenoid
Part Number: 4884495AF$479.60 MSRP: $734.00You Save: $254.40 (35%)Product Specifications- Other Name: Manifold-Intake
- Replaced by: 4884495AK
Product Specifications- Other Name: Plenum-Engine Intake; Intake Manifold
- Replaces: 53032761AJ, 53032761AG, 53032761AH, 53032761AI
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 5184199AF
Product Specifications- Other Name: Manifold Intake Includes All Items In The Box
- Replaced by: 4884495AK
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 4884495AK
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 4884495AK
Product Specifications- Other Name: Manifold Intake Includes All Items In The Box
- Replaced by: 4884495AK
Dodge Engine Intake Manifold Kit
Part Number: 68189105AB$580.80 MSRP: $889.00You Save: $308.20 (35%)Product Specifications- Other Name: Manifold-Engine Intake; Intake Manifold
- Replaced by: 68189105AC
Product Specifications- Other Name: Intake Manifold
- Replaces: 68525628AC, 68525628AB, 5281512AF, 5281512AE, 5281512AL, 5281512AG, 5281512AI, 5281512AK, 5281512AD, 5281512AJ, 5281512AH, 5281512AM, 68525628AD
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 53034181AD
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 4593915AB
Product Specifications- Other Name: PLENUM Intake Manifold; Intake Plenum, Plenum
- Replaces: 4591863AL
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 53034181AD
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 4884495AK
Product Specifications- Other Name: Manifold-Intake
- Replaced by: 4884495AK
Product Specifications- Other Name: PLENUM Intake Manifold See Important Note
- Replaces: 4781578AM, 4781578AL
| Page 1 of 10 |Next >
1-20 of 184 Results
Dodge Intake Manifold
Our website provides genuine Dodge Intake Manifolds at competitive prices in the market. All of our OEM Dodge Intake Manifolds come with the assurance of the manufacturer's warranty, a stress-free return policy, and speedy delivery service. So, you can shop with confidence.
Dodge Intake Manifold Parts Questions & Experts Answers
- Q: How to remove and install the engine cover and intake manifold in V8 engine on Dodge Challenger?A:To remove the engine cover, first take off the oil cap and lift the cover off the four support grommets. Relieve the fuel system pressure and disconnect the cable from the negative terminal of the battery, ensuring that on 2015 and later models with an Intelligent Battery Sensor, the IBS connector is disconnected first. Next, remove the air filter housing and the intake air duct, followed by the ignition coils and, for 2005 models, the spark plug wires. Disconnect the brake booster vacuum hose, canister purge hose, and the PCV hose. As a precaution, remove the fuel rails and injectors. For 2010 and earlier 5.7L engines, remove the EGR pipe from the intake manifold. Disconnect the electrical connectors from the MAP sensor and the throttle body. Loosen the intake manifold bolts starting with the outer bolts and working inward in 1/4-turn increments until they can be removed by hand, then take off the intake manifold, checking for and disconnecting anything still attached. When installing, ensure the mating surfaces of the cylinder heads and intake manifold are perfectly clean, avoiding harsh chemicals on the plastic manifold. Check the O-rings on the intake manifold for damage; if they are fine, they can be reused, otherwise, install new ones ensuring they seat properly. Carefully set the manifold in place without disturbing the rubber seals or moving it after contact with the cylinder heads to prevent vacuum and oil leaks. Install the intake manifold bolts and tighten them following the recommended sequence to the specified torque. The remaining installation steps follow the reverse order of removal, and after starting the engine, check for vacuum leaks at the intake manifold joints.
- Q: How to remove and install an intake manifold in V8 engine on Dodge Charger?A:First start by taking off the engine cover on vehicles built after 2006. Turn off fuel pressure and remove battery's negative lead. Then pull off the parts that hold the air filter and guide air into the engine. Disconnect these three hoses: the brake booster vacuum hose, canister purge hose, and PCV hose. Start with these three removals: the fuel rails and injectors, then the EGR pipe from the intake valve. Remove the electrical wires from the MAP sensor and throttle body. Start by turning the intake manifold bolts 1/4-turn at a time, starting with the ones on the outside. Keep going inward until you can remove all bolts by hand, afterward take off the intake manifold, being careful to disconnect any remaining parts. Make sure to clean the mating areas on the cylinder heads and intake manifold first, and stay away from rough chemicals that might harm the plastic intake manifold. Look at the O-rings on the intake passage box for damage. If they're good, you can use them again, but replace them if they're not working right. Be very careful when you put the intake manifold down into place, and don't move it once it touches the cylinder heads to avoid leaks. When you install the intake manifold bolts, bolt them down in the required order and make sure you give each bolt the correct amount of torque. To finish the job, start with the engine, then work backwards through the other steps of booking, and check for leaky vacuum joints on the intake manifold.
- Q: How to remove and install the intake manifold in 3.7L V6 engine on Dodge Nitro?A:In order to take out the intake manifold, one has to relieve the fuel pressure and then loosen the cable from the negative terminal of the battery. Then, unbolt the air intake duct from the throttle body and also cap and tag the vacuum lines for the PCV valve and the power brake booster, the cruise control servo and the evaporative emission control. Remove bulb sockets from respective sockets for the various sensors, ignition coils, and Idle Air Control motor, and also for the alternator and air conditioning compressor. Remove the ground straps that are fastened to the intake manifold and throttle body; then remove the nut of the engine oil dipstick as well as the dipstick tube from the engine block. Disconnect the throttle and cruise control cable from the throttle body and bracket and ignition coils. Place the fuel rails, the throttle body and the mounting bracket aside and siphon the coolant as well as pull the heater hoses. Take the coolant temperature sensor out of the way and, on 2007 and later models, snap the EGR tube. Unbolt the intake manifold coming in their order, but be very careful not to scratch the gasket flares. Disconnect and remove any hose labels that are still connected to the manifold and get rid of any hoses that might hinder the process then lift the manifold and take it off the engine. For installation, clean and check the condition of the intake manifold and gaskets if they are worn out or damaged they should be replaced. Set the manifold to the engine in a manner that is correct and then screw in the nuts and bolts until it is just slightly tight. Then, based on the above tightening sequence, tighten the bolts to the prescribed torque. To complete the procedure reverse the above steps of removal, refill the cooling system, engage the engine, and examine for signs of leakage.
