Genuine Dodge Oil Pump
Oil Fluid Pump- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
92 Oil Pumps found
Product Specifications- Other Name: Pump-Engine Oil; Oil Pump
- Replaces: 68252670AO, 68252670AM, 68252670AN
Product Specifications- Other Name: Pump Engine Oil; Oil Pump
- Replaces: 53021622BF, 53021622BG, 53021622BB, 53021622BE
Product Specifications- Replaced by: 68252670AP
Product Specifications- Other Name: Pump Engine Oil; Oil Pump
- Replaces: 68045796AA, 53020827AB
Product Specifications- Other Name: Control Solenoid
- Replaces: 5048437AA, 5048437AB
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53021622BH
Product Specifications- Other Name: Pump Engine Oil; Oil Pump
- Replaces: 53021622AD, 53021622AE
Product Specifications- Other Name: Pump-Engine Oil
- Replaced by: 68252670AP
Product Specifications- Other Name: Pump Engine Oil; Oil Pump
- Replaces: 5038398AD, 5038398AC, 5038398AB
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53021622BH
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53020827AC
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53020827AC
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53021622AF
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53021622BH
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 5047363AD
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 68195993AD
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 68195993AD
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 5038398AE
Product Specifications- Other Name: Pump Engine Oil
- Replaced by: 53021622AF
Product Specifications- Other Name: Pump-Engine Oil; Oil Pump
- Replaces: 68195993AB, 68195993AC
| Page 1 of 5 |Next >
1-20 of 92 Results
Dodge Oil Pump
Our website provides genuine Dodge Oil Pumps at competitive prices in the market. All of our OEM Dodge Oil Pumps come with the assurance of the manufacturer's warranty, a stress-free return policy, and speedy delivery service. So, you can shop with confidence.
Dodge Oil Pump Parts Questions & Experts Answers
- Q: How to remove and install the oil pump in V8 engine on Dodge Challenger?A:To remove the oil pump, the cable should then be disconnected from the negative terminal on the battery, note on 2015 and later models with an IBS connector the IBS should be disconnected before the negative battery cable. Second, dump the cooling system, third, take off the timing chain cover and the oil pan. Subsequently, seize the bolt that connects the pick-up tube assembly, to drop it aside from the oil pump, in addition to the bolts that hold the oil pump to the engine block. For installation the pump is to be placed at the engine and the pump rotor should be parallel to the crankshaft drive and the oil pump mounting bolts are to be fitted and tightened. Slide in a new O-ring on to the oil pump pick-up tube and fasten it to the pump with the help of the bolt and tighten it. The remaining of the installation process is in the exact opposite order of uninstallation. At last, add the correct grade and amount of oil in the crankcase and replace the oil filter; check the level of the coolant and replenish if necessary; start the engine and examine its performance and efficiency in terms of oil pressure and existence of oil leaks.
- Q: How to remove and install the oil pump and timing chain cover in 3.3L and 3.8L V6 engine on Dodge Grand Caravan?A:To replace the oil pan pull off the timing chain cover then take out the oil pump cover bolted to the timing chain cover by applying power on the Torx drive socket. Shine all of them in the solvent and inspect the rotor, pump cover and timing chain cover for any nicks, scratches or burrs the entire assembly should be replaced. With the straightedge utilize the feeler gauge to measure oil pump cover for warpage; if in excess of limit, replace the pump. Check the thickness of the outer rotor and replace the pump if it is anything below the thickness should be. Measuring the thickness of the inner rotor with a micrometer: replace the pump, if this diameter is less than the allowable one. Fit the outer rotor into the timing chain cover/oil pump housing and check the gap when the rotor would be in its highest position; if this gap is larger than the maximum permissible gap, then change the pump. Insert the inner rotor in the oil pump assembly and check the leakage between the lobes of inner and outer rotor replacing the pump in the event leakage is greater than mentioned above, be certain that the arrow marked on the inner rotor is up. Place a straightedge on the face of the oil pump assembly, and using a micrometer measure the distance between the surface of the pump and the rotors; if the distance is more than the recommended limit you replace the pump. On installations, tighten the pump cover bolts to the torque of your choice, ensure that the flats in the rotor slotting match those of the crankshaft when fixing the pump and then fit the timing chain cover and fixed by the right torque. The following steps involve the reversal of the Remove steps covered above in order of installation.
- Q: How to remove and install the oil pump in six cylinder engine on Dodge Ramcharger?A:Remove the oil pump cover and outer rotor, ensuring that the outer rotor does not drop to avoid damage. Unscrew the mounting bolts to detach the pump from the crankcase. For installation, reverse the removal process, using a new gasket, lubricating the parts before installation, and tightening the cover bolts to the specified torque.
